Description

VTS 2-2 DS – Dual-Car Deep Shaft Vertical Transport System

Engineered for Strength. Built for Canada.

The VTS 2-2 DS is Romax’s extended-travel dual-car lift system—expertly designed to vertically transport two vehicles simultaneously with the same exceptional reliability, safety, and craftsmanship as the original VTS 2-2, but now with travel distances of up to 24 feet. Proudly built in Toronto and engineered for Canadian conditions, the VTS 2-2 DS delivers powerful performance for multi-level garages, deep shafts, and custom architectural spaces.

Key Features & Benefits:

‍

Enhanced Dual-Car Capability

The VTS 2-2 DS is structurally reinforced and engineered to lift two vehicles at once, provided there is sufficient ceiling height. It offers the same smooth hydraulic operation and customizability as the original VTS 2-2, now with expanded vertical reach for deeper applications.

Premium Construction

Built with top-grade Canadian materials, the VTS 2-2 DS features a robust hydraulic drive system and reinforced steel structure to accommodate dual-vehicle lifting with maximum stability.

High Load Capacity

Each platform is rated to support up to 6,000 kg total (3,000 kg per vehicle), making it ideal for lifting combinations of sedans, SUVs, pickup trucks, and electric vehicles.

Flexible Design

With over 20 standard platform sizes and full customization options, the VTS 2-2 DS is perfect for high-end residential garages, underground vaults, or deep-shaft applications. A common platform size—10 x 20 feet—allows vertical travel of up to 24 feet, ideal for accessing lower garage levels or basement storage areas.

Weather-Resistant & Leak-Proof

Fully sealed between levels and equipped with an integrated drainage system, the VTS 2-2 DS is designed to perform reliably year-round, even in harsh Canadian climates.

Durable Industrial Finish

Each unit is sandblasted and coated with industrial-grade epoxy primer and paint to ensure superior corrosion resistance and long-term durability.

Safety & Control Systems

• Comprehensive Safety Features
  Key operation and emergency stop buttons at all control points
• Interlocking Door System:
  • Main garage door opens only when the lift is at the top or bottom
  • Basement/lower garage door opens only when the lift is at the bottom
  • All doors, including man doors, are locked while the lift is moving or between levels
• Photoelectric Sensor:
  Detects over-height vehicles on the top platform and stops movement before ceiling collision
• Dual Camera and Monitor System:
  View opposite levels while operating the lift from a single floor
• Velocity Fuses (Overspeed Valves):
  Installed in each hydraulic cylinder to instantly block fluid flow if speed exceeds a safe threshold—preventing free-fall or rapid descent

Optional Enhancements

• Custom automation and wireless remote control with safety protections
• Smart sensor systems for hands-free or guided operation
• Lighting and garage integration packages
• Car position detection: Halts lift if a vehicle is not correctly positioned on the platform
• Vehicle door safety system: Disables lift movement if a car door is left open, avoiding potential damage

Installation & Compliance:

‍

Turnkey Installation

From design to final installation, Romax handles every step of the process, ensuring a seamless, efficient experience.

Permits & Inspections

We supply all required documentation for building permits, as well as ESA permits and inspections. Romax is fully TSSA-registered for installation and servicing of lift systems across Ontario.

Client Involvement

Clients are encouraged to visit our Toronto production facility during fabrication to witness the care and quality that goes into each unit.

Why Choose the VTS 2-2 DS?

Designed for multi-level garages, deep shaft designs, and projects that demand extended vertical reach, the VTS 2-2 DS delivers the lifting power, space optimization, and dependability required for even the most ambitious builds.

For those who require more from their space—Romax delivers.
You dream, we build.
